Látum okkur annt um loftið

sem við öndum að okkur

Testo Smart Probes - mælar og mælasett sem tengjast snjallsímum með testo smáforriti "App" gegnum wifi og birta mælingar og útreikninga
á síma. Niðurstöður má senda sem pdf á emaili.
Fáanleg eru sett sem henta til mælinga og stillingar á kælivélum og varmadælum, á loftræstikerfum og á hitakerfum.

Smart Probes Kælisett
Sett f. mælingar og stillingar á kælitækjum og varmadælum. Mælingar á hita og vökvaþrýstingi.
The testo AC/R Smart Probe Set is a combination of four instruments to measure high-side and low-side pressures and temperatures of A/C and refrigeration systems. Configured to be used during commissioning, servicing, PM and troubleshooting A/C and refrigeration systems. This kit can be operated with no tools other than your smart phone to communicate with the instruments.
Key Features:
Measure high-side & low-side refrigerant pressure & temperatures (simultaneously) of AC/refrigeration systems
Low-loss AC/R system checks. No hoses required!
Complete and compact wireless AC/R test kit
Calculate superheat and subcooling in the Smart Probe App
Order no. 0563 0002
Nánar um Kælisett

Smart Probes f. HVAC sett
Sett f. mælingar á loftræstikerfum. Mælingar á hiti, raka og lofthraða.
The testo VAC Smart Probe Set provides a combination of four Smart Probe instruments used with your Smart Device needed to test and balance a multi-outlet ventilation system. Two types of anemometers give you the capacity to measure in-duct air flow and the flow from each vent. Using an IR temperature probe for surface temperatures will show you motor and electrical equipment conditions and an easy check of each outlet. The thermohygrometer will provide an assessment of the humidity and dewpoint concerns throughout the system.
Key Features:
Measures air velocity, temperature, relative humidity, wet bulb / dew point, and calculate volume flow
Kit includes instruments to measure, balance, troubleshoot, and optimize ventilation systems performance
RH & air flow measurements in-duct and at registers viewed simultaneously in the testo Smart Probes App (605i, 405i, 410i)
App calculates system enthalpy with air flow & RH probes; App allows you to photograph objects with smart device, capturing measurement marker and temperature values for reference and reporting (805i)
Order no. 0563 0003
Nánar um HVAC sett

Sett f. mælingar á hitakerfum. Mælingar á hita á lögnum.
The testo Hydronic Heating System Smart Probe Set contains three instruments designed for use on a hydronic heating system to determine gas flow and static pressure, measure temperature of radiators with an IR probe, and to measure pressure leak-down tests in piping systems.
Key Features:
Measures manifold gas pressure, pressure drop, air flow, (with optional pitot tube), pipe and radiator temperatures
Perform timed pressure leak-down tests on pipe systems
Measures temperature of pipes in heating and cooling systems with accurate and stable NTC temperature sensor
Photograph objects with smart device, capturing measurement marker and temperature values for reference and reporting (805i)
Order no. 0563 0004
Nánar um hitunarsett

Smart própa -hitamælir f. yfirborðsmælingar á hita- og kælilögnum
testo 115i
- Pipe-clamp Thermometer Smart and Wireless Probe
The testo 115i Smart Probe is a pipe-clamp probe that measures temperature in pipes more accurately than thermocouples because of the superior NTC temperature sensor technology. The exclusive Testo probe design grips pipes up to 1.5” and maintains critical contact between probe and pipe surface to derive the best readings.
Key Features:
Measures temperature of pipes in heating and cooling systems
Use with testo 549i Refrigeration Pressure Probe to calculate superheat and sub-cooling
Quickly identify temperature changes by monitoring real-time trending and data logging
115i NTC temperature sensor is more accurate and stable than thermocouples
Order no. 0560 1115

Smart próba - þrýsimælir f. mælingar á vökvaþrýstingi kælilagna.
testo 549i
- Refrigeration Pressure Smart and Wireless Probe
The testo 549i Smart Probe is a hose-less, wire-less, pressure probe for measuring refrigerant charge in AC/Refrigeration systems. It is used for servicing, troubleshooting, and documenting the operation of residential or commercial AC/refrigeration systems. When two 549i are used in conjunction with two 115i pipe-clamp temperature probes it is easy to monitor superheat and sub-cooling in AC/refrigeration systems.Measures high-side or low-side refrigerant pressure (or both simultaneously with 2 probes) in AC/refrigeration systems
No hoses required! Clean, simple, accurate.
Low-loss refrigerant pressure testing!
Order no. 0560 1549

Smart própa - lofthraðamælir f. mælingar á lofthraða
testo 405i
Smart Probe hot-wire anemometer is a wireless instrument for measuring air flow velocity, temperature, and volume flow. It is equipped with a telescopic shaft which extends to 15” for easy in-duct testing. You can reliably determine timed and multipoint flow traverses.
Key Features:
Measures air velocity, volume flow, and temperature
Measures in-duct air flow and automatically calculates volume flow (enter duct dimensions simply). Small dia. (<0.5”) and 15” telescopic shaft length is ideal for in-duct flow averaging and timed traverse. Perform air duct leakage tests
Order no. 0560 1405

Smart própa - lofthraðamælingar í ristum
testo 410i
Smart Probe is a compact wireless vane anemometer for measuring air velocity, and temperature and deriving volume flow. It is used at air outlets, and for monitoring the air flow of ventilation systems.
Key Features:
Measures air velocity, volume flow, and temperature as well as air flow at registers and automatically calculates volume flow (enter duct dimensions simply)
No air density correction required due to design
Measure volume flow at several outlets simultaneously (using mutiple Smart Probes) to adjust system balance
Timed/multipoint averaging to get accurate air flow profiles
Order no. 0560 1410

Smart própa - rakamælingar
testo 605i Smart Probe
thermo-hygrometer is a humidity and temperature measuring instrument that quickly and accurately measures relative humidity, dew point, and temperature in rooms, ducts, registers, and environmental boxes/chambers.
Quickly and accurately measures relative humidity and temperature in rooms, ducts, and chambers
Automatically calculates dew point & wet bulb temperature
Small diameter probe is ideal for in-duct measurements
Order no. 0560 1405

Smart própa - geislahitamælir smart and Wireless Probe
testo 805i Smart Probe
is an infrared (IR) thermometer that provides non-contact temperature readings; great for checking breakers, motors, ducts, and registers from a distance. The measurement area is indicated by a circular laser pattern which asssures accurate targeting measurement.
Key Features:
Measures non-contact temperature
Optic target ratio (10:1)
Measurement area indicated by circular laser pattern assures accurate assessments
Photograph objects with smart device, capturing measurement marker and temperature values for reference and reporting
Order no. 0560 1805

testo 510 i - Mismunaþrýstimælir f. loft
testo 510i Smart Probe
is a wireless differential pressure probe used for accurate low-pressure measurements. The testo 510i is great for measuring pressure in manifolds, static pressure, and pressure drops in buildings or ventilation systems. Use it to measure the pressure drop across coils and filters or in ducts and systems.
Key Features:
Differential pressure (manometer) measures static pressure, air flow, and volume flow (with Pitot tube not incl.)
Measures manifold pressure and pressure drop across filters and coils and has measurement menu in App that includes pressure drop alarms
Easy configuration and calculations for volume flow (enter pitot tube factor and dimensions easily)
Magnetic back holds instrument for hands-free operation
Order no. 0560 1510

Wireless control of the Testo Smart Probes
Calculate evaporation / condensation temperature and superheating / subcooling
Analyze measurement data, add photos and send them by e-mail
Download for iOS
Download for Android
